PBE-1400 CNC PANEL BENDER EDGE FOLDING MACHINE
Bending Size: 1400*1400mm
Bending Height: 170mm
Bending Angle: 0-180KW
No installation required
Simple operation
Support video teaching
1 Year for machinery warranty
On Stock
Email : contact@antsmachine.com
(your request will be responsed within 1 hour.)
Technical Parameter :
| Model | Unit | PBE-1400 | |
| Nominal Force | KN | 250 | |
| Bending Size | mm | 1400*1400 | |
| Bending Height | mm | 170 | |
| Min. Forming Size of Four Side | mm | 200×110 | |
| Min. Forming Size of Single Side | mm | 110 | |
| Min. Arc Radius | mm | 2 | |
| Bending Angle | KW | 0-180 | |
| Min .Sheet Thickness | mm | 0.35 | |
| Bending Process | Stainless Steel | mm | 1.0 |
| Steel | mm | 1.5 | |
| Aluminum | mm | 1.6 | |
| Rated Voltage | V | 380±10% | |
| Dimension | Length | mm | 3000 |
| Width | mm | 2000 | |
| Height | mm | 2600 | |
PBE-1400 CNC PANEL BENDER EDGE FOLDING MACHINE Product Introduction :
PBE Series
The multilateral bending center does not need to change the mold, the working stroke is short, and the feed is fast. Comprehensive efficiency is 3 to 4 times that of manual bending machine. According to the bending process, it can be automatically folded up and down, so as to realize the bending of arcs, dead edges, and various angles. Highly intelligent operation control system, which can efficiently bend different workpieces. Energy saving and consumption reduction, reducing labor and mold costs.
Main Components Configuration
| No | Item | Description | Brand |
| 1 | Controlling System | HC15E-S Touch Screen | SYNTEC |
| 2 | Servo Driver | BUS Control | SYNTEC |
| 3 | Servo Motor | H & F Series | SYNTEC |
| 4 | Motor Reducer | SIGRINER | |
| 5 | Ball Screw | Heavy Load | YIGONG |
| 6 | Bearing | NACHI | |
| 7 | Linear Guide | HIWIN/PMI | |
| 8 | Coupling | MIKIPULLEY | |
| 9 | Lubrication System | BAOTN | |
| 10 | Electric Component | Schneider | |
| 11 | Pneumatic Component | AirTac/JULY |
Configuration
| Name | Configuration |
| Feeding Type | Arm Hold Dual Rotate |
| Table Type | Brush |
| CNC Axes | 11 |
| Speed Adjustment | Standard |
| Senior Command | Standard |
| Arc Command | Standard |
| HEM Command | Standard |
| Robot Connection | Standard |
