Specifications		DW18CNC-4A-1S	Remark
Maximum bending pipe diameter ×Wall thickness		Φ18mm×1.6mm	1. The minimum bending radius is based on the diameter of the pipe. 2. Maximum bending radius can be according to customer requirements. 3. The maximum core length can be according to customer requirements.
		Carbon steel pipe
Maximum bending radius		R80mm
Minimum bending radius		R≧1.2D
Maximum bending Angle		190°
Maximum feeding length		1800mm
Feeding method		Direct delivery
		Clip
Working speed	Bending speed	Max 200°/s
	Tubing speed	Max 200°/s
	Feeding speed	Max 1000mm/s
Working accuracy	Bending accuracy	±0.1°
	Tubing accuracy	±0.1°
	Feeding accuracy	±0.1mm
Information input mode		1. coordinate(X . Y. Z)
		2. Working value(Y. B. C)
Bend way		Servo bending
Corner servo motor		400w
Feed servo motor		750w
Left and right mold changing servo motor		400w
Bending servo motor		1.5kw
Pipe fittings allow elbows		50
Number of parts that can be stored		500
Oil motor power		4kw
Maximum system pressure		12 Mpa
Machine dimensions		3000 x 700 x 1200mm
Machine weight		1400kg

Features

1.A touch screen display, CNC computer operation, can store 500 sets of memory.

2.Rebound compensation value setting procedures, procedures and processing data security functions.

3.Corner, feeding, bending are servo controlled.

4.The operating system is equipped with password, key, and quantity and time record for production management.

5.It has the function of slow bending and slow core pulling.

6.Error messages are displayed on the screen to help the operator clear them immediately.

Main Parts for the machine

Name	Specification	Supplier
Hydraulic motor	4KW	China
The oil pump	PVL1-17	China
Pressure valve	02W	Taiwan’s seven ocean
Solenoid valve	G02-2C-DC24	Taiwan’s seven ocean
The overflow valve	2B3B-D24	Taiwan’s seven ocean
Sealing ring	/	Taiwan CHO
Pressure gauge	0-25Mpa	China
AC contactor	LCED1801	Taiwan TAIAN
touch screen	10 inch	China
Switching power	24V	Taiwan MEAN WELL
Corner servo motor	400W	Japan MITSUBISHI
Feed servo motor	750W	Japan MITSUBISHI
Left and right mold changing servo motor	400w	Japan MITSUBISHI
Bending servo motor	1.5kw	Japan MITSUBISHI
Smart transformer	RP-3	China
Linear Guide	20*2200	Taiwan
1.Corner reducer 2.Feed reducer 3.Mold changing reducer 4.Bending reducer	1. GPL70-32 2. GPLF90-5 3. GPLF65-5 4. GPLF120-40	China
Central controller	ICM-880W04	China
Relay	RXM2MB	Taiwan TAIAN
thermal relay	LR-16B	Taiwan TAIAN
Induction switch	24V	China

Remark：The accessories in the configuration list allow the manufacturer to change the accessory brand to a higher level according to the material supply. Users can purchase other brand accessories according to their needs.
