scissors type horizontal band saw machine (CS-220)
Warranty : 1 Year for machinery warranty
Availability : On Stock
Email : contact@antsmachine.com
(your request will be responsed within 1 hour.)
Product description:
● Mainly used for sawing all kinds of ferrous and non-ferrous metals;
● The utility model has the advantages of reasonable structure, stable performance, high reliability and high precision, and is an ideal device for cutting medium and small batches.
| Sawing Capacity(mm) | Round material: Ø220 mm Square material: 400w x 100h |
Band saw wire speed(m/min) | 21 / 34 / 43 / 60 |
| Band saw wire specifications(mm) | 27 x 0.9 x 3045 | Main motor power(kw) | 1.5（4p） |
| Hydraulic motor(kw) | Cooling pump(kw) | 0.06 | |
| Work clamping method | Manual clamping | Saw blade tensioning method | Manual |
| Main drive structure | Worm gear drive | Feeding mode | Auxiliary roller table |
| Height of table(mm) | 640 | Overall size(mm) | 1600 x 610 x1130 |
* The series of machine tools are semi-automatic and automatic, automatic machine tool adopts PLC control, touch screen can preset 5 sets of sawing process parameters.
* A saw cutting device can be configured according to requirements.
