Horizontal Mitre Cutting Bandsaws

Horizontal Mitre Band Saw Machine BS-1018B

Warranty : 1 Year for machinery warranty

Availability : On Stock

WhatsApp : +86-19534031668
Wechat : +86-19534031668
Email : contact@antsmachine.com
(your request will be responsed within 1 hour.)

Model BS-1018B
Machining capacity Round steel@90° 254mm(10″)
Square steel@90° 127×457mm(5″×18″)
Round steel@45° 150mm(6”)
Square steel@45° 150×190mm(6″×7.5″)
Saw cutting speeds @ 60HZ 35,60,88,115MPM
@ 50HZ 29,50,73,95MPM
Saw blade size 27×0.9×3280mm
Motor power 1.5W 2HP(3PH)
Drive V-belt
Package size 1830×830×1150MM
NW/GW 310/385kg

For high precision metal cutting, is the ideal equipment for the industrial and mining enterprises and small workshops, use is very extensive.Cuts almost anything that you can throw at it, including many different shapes and profiles of metal.Variable cutting speeds allow you to fine-tune the saw for better cut quality.

Features:
1.The maximum processing capability of BAND SAW BS-1018 is 10″(254mm)
2.High-capacity due to controlled by motor
3.Can rotate from 0° to 45°
4.Has the advantage of quickly clamping.
5.Features a belt driven and has four cutting speed.
6.The falling speed of saw bow is controlled by hydraulic cylinder
7.With a sizing device, machine will stop automatically after sawing materials
8.With power break protection device, machine will power off automatically when the rear protective cover is opened
9.With coolant system, can prolong the service life of saw blade and improve the precision of work piece
10.Has a block feeder (with fixed sawing length)

Standard Equipment
1 saw blade
Base
operator instructions
operating tools

Optional Equipment
Quick-action vise
hydraulic cylinder for saw frame
Saw Blade
Saw Band Clamping
Bi-Metallic Bandsaw Blade
Coolant Concentrate 5 Ltr.
coolant system
Infeed roller table(1/2/3 meter )
Outfeed roller table with stopper(1/2/3 meter )
Automatic band break control
Bundle vise
Hydraulic part clamping
Chip wiper
