630GS3 Medium-Speed Wire cut Electrical Discharge Machine

630GS3 Medium-Speed Wire cut Electrical Discharge Machine Product Introduction :

630GS3 AC servo medium-feeding wire-cutting machine tool is an upgraded version of 500GS1. It is a five-axis CNC (“Z” axis CNC manual lock) four-axis linkage medium-feeding wire-cutting machine tool. The “Z” axis can realize micron-level CNC control , The U/V axis adopts precision linear guide rail, ball screw and motor are directly connected. This model of Shanghai ANTISHI is the first servo medium-feeding wire-cutting machine tool in China to adopt this structure to achieve stable processing.

In order to better achieve higher precision of our products, better product consistency, and more stable product stability. For this reason, Shanghai ANTISHI has introduced a German ZEISS three-coordinate measuring instrument for three-dimensional inspection and screening of machine tool castings and purchased parts.

Features

1.Machinery

(1) The fuselage is integrally cast with high-quality resin sand, and has been tempered twice, and then processed by special means to eliminate the internal stress of the casting, ensure that the machine tool will not deform for a long time, and ensure the continuous maintenance of machine tool accuracy.

(2) The “T” shaped bed base and slow wire structure are adopted to improve the stability of long-term processing.

(3) The overall machine tool adopts a “C”-shaped structure, which is stable in structure and better in precision retention.

2.Mechanical inspection

(1) Machine tool components are inspected in strict accordance with Swiss manufacturing standards and inspection standards.

(2) All key components of the machine tool have been strictly inspected by advanced imported testing instruments such as German ZEISS three-coordinate measuring instrument and German height measuring instrument.

(3) British RENISHAW laser interferometry strictly inspects the positioning accuracy and repeat positioning accuracy of machine tools.

(4) Shanghai ANTISHI ensures that the internal control standard of each machine tool is higher than the national standard.

(5) Pursue “fine workmanship” in every step.

3.Drive and control

(1) Swiss standard custom imported precision ball screw and precision ball guide.

(2) The imported precision ball screw is directly connected with the Japanese AC servo motor, which has higher precision and longer retention.

(3) Swiss standard customized high-precision bearings, large-scale motors, and bearing mounts.

4.Water tank filtration and environmental protection processing

(1) Multi-stage filter water tank. Fully enclosed sheet metal design, more reliable structure.

(2) Long-term processing without water mist splashing, processing is more hygienic and more environmentally friendly.

5.Advantages of CNC power supply

(1) The CNC power supply has an adaptive control loop to ensure that it is not easy to break the wire during high-current processing.

(2) Ultra-low molybdenum wire loss circuit.

(3) The CNC power supply has an AC power supply control circuit; high voltage and low voltage circuits.

(4) The high-end body is equipped with a high-performance CNC power supply, which can not only obtain high efficiency and ultra-low molybdenum wire loss during rough machining, but also obtain ultra-high smoothness during knife repairing.

(5) The Auto-Cut system supports graphic-driven automatic programming, and the user does not need to touch the code, but only needs to set the processing technology for the processing graphic to process, and the software can be directly embedded into various versions of software such as Auto CAD and CAXA;

(6) A variety of processing methods can be combined flexibly (continuous, single-stage, forward, reverse, reverse, etc.)

(7) Real-time monitoring of the X, Y, U, V four-axis processing status of the wire cutting machine tool;

(8) Processing preview, real-time display of the processing process; 3D tracking display can be performed during taper processing, the graphics can be zoomed in and zoomed out, and the processing situation can be observed from multiple angles such as the front view, left view, and top view;

(9) It can be cut once or multiple times to improve the processing speed and finish.

(10) With user-maintainable process library function, it makes multiple processing simple and reliable;

(11) The processing of taper work-piece adopts five-axis numerical control and four-axis linkage control technology, which can conveniently process the upper and lower special-shaped surfaces, making the processing of complex taper graphics simple and accurate;

(12) It has an automatic alarm function, which will automatically alarm when the processing is completed or when there is a failure, and the alarm time can be set;

(13) Support corner clearing and delay processing, and delay processing at the corner of the track to improve the deviation caused by the bending of the electrode wire;

(14) Support the backlash compensation function, which can compensate the screw backlash error of the machine tool to improve the accuracy of the machine tool;

(15) It has three languages of Chinese, English and Russian, which creates a good language environment for product export.

(16) The imperial coordinate position can be queried at any time during processing, which solves the conversion problem in imperial countries (such as the United States).
