Main specifications	GY40NC-7	Remark
Max. pipe bending capacity	Φ40mm x 2mm	Specifications can be according to customer requirements
Mini. elbow radius	R≧7.5D
Bending speed	adjustable
The mold diameter	127mm
Total power	4kw
Machine size	1850mm x 850mm x1050mm
Machine weight	720kg

Features

1.Full mechanical transmission, compact structure, high reliability.

2.The equipment is equipped with three, seven, nine wheel drive, not easy to slip, thin wall material can also bend.

3.Two sides of the wheel asymmetrical distribution, reduce the straight line segment.

4.Both sides of the side wheel can feed the work-piece.

5.Foot switch with emergency stop function, easy to operate.

6.The machine transmission balance only need to adjust the pressingtoobtain different curvature of the circular, arc or spiral shape.

7.Change the mold groove, can process all kinds of metal profiles, such as Angle steel, flat steel, round pipe and other special-shaped section profiles.

8.It can bend large radius profiles to avoid the disadvantages of making large bending die. It is the necessary supplement that single head and double head series bending machine can not reach.

Main Parts for the machine

Specifications	Supplier
Machine frame	China
Major electrical appliance	Taiwan TAIAN
Hydraulic valve	Taiwan 7OCEAN
Overflow valve	Taiwan 7OCEAN
Electric motor	China
High pressure tubing	China
Oil pump	China
Emergency stop switch	China
Switching power supply	Taiwan MEAN WELL
Bearings	China
The mold	China

Remark：The accessories in the configuration list allow the manufacturer to change the accessory brand to a higher level according to the material supply. Users can purchase other brand accessories according to their needs.
