Specifications
|
Units
|
MY1022
|
||
|
workbench
|
Worktable size (L * W)
|
mm
|
540×250
|
|
|
Max. travel of table
|
mm
|
560×260
|
||
|
Table T slot (slot number x slot width)
|
mm
|
1×14
|
||
|
Grinding head
|
The grinding wheel size (o. d * w * i. d.)
|
mm
|
φ200×20×Φ31.75
|
|
|
Distance spindle center line to working table
|
mm
|
450
|
||
|
Grinding wheel speed
|
50HZ
|
r/min
|
2850
|
|
|
60HZ
|
r/min
|
3360
|
||
|
The amount of feed
|
Table longitudinal (left and right) speed
|
m/min
|
3-20
|
|
|
Table transverse (front and rear) feed handwheel feed
|
Continuous (stepless)
|
mm/min
|
600
|
|
|
Intermittent (stepless)
|
mm/times
|
0-5
|
||
|
Handwheel per turn
|
mm
|
4.0
|
||
|
Handwheel per lattice
|
mm
|
0.02
|
||
|
The vertical (up and down) feed handwheel feed
|
Handwheel per turn
|
mm
|
1.25
|
|
|
Handwheel per lattice
|
mm
|
0.01
|
||
|
Hydraulic system
|
Hydraulic motor
|
kw
|
1.5
|
|
|
working pressure
|
Mpa
|
3
|
||
|
Fuel tank capacity
|
L
|
80
|
||
|
Maximum flow rate
|
L/min
|
18
|
||
|
Motor power
|
Spindle motor
|
kw
|
1.5
|
|
|
Cooling motor
|
W
|
40
|
||
|
working accuracy
|
The process surface of the base level of the parallel degree
|
mm
|
300:0.005
|
|
|
Surface roughness
|
μm
|
Ra0.32
|
||
|
Machine weight
|
Net weight
|
kg
|
950
|
|
|
Gross weight
|
kg
|
1050
|
||
|
External size (L * w * h)
|
mm
|
1680x1220x1720
|
||
|
Packing size (L * w * h)
|
mm
|
1730x1290x1940
|
||
