Specifications
|
Units
|
4H
|
5H
|
Table size
|
mm
|
1270×254(10”x50”)
|
1370×305(12”x54”)
|
Table travel
|
mm
|
780/400/420
|
780/ 420 /420
|
T slot(number-width-pitch)
|
mm
|
3-16-50
|
3-16-65
|
Spindle taper
|
(standard):R8
(optional):ISO40 |
(standard):R8
(optional):ISO40 |
|
Spindle speed range
|
rpm
|
(standard):(16 steps)50HZ:65-4500 60HZ:80-5440
|
|
(optional)(variable)65-4000
|
|||
Spindle travel
|
mm
|
127
|
127
|
Spindle feed range
|
mm
|
0.04,0.08,0.15 (3 steps)
|
0.04,0.08,0.15 (3 steps)
|
Distance between spindle nose and table surface
|
mm
|
90-510
|
90-510
|
Main motor power
|
kw
|
2.2
|
2.2
|
Head rotation (left – right )
|
°
|
±90°
|
±90°
|
Head rotation (front – rear)
|
°
|
±45°
|
±45°
|
Weight
|
kg
|
1400
|
1600
|
Overall dimension
|
mm
|
1550x1650x2250
|
1550x1650x2250
|
