MAIN FEATURES
2-Axes Digital readout system. Metric & inch gear box with full range of inch, metric, DP, MP threading and multiple threads, all function shall be reached without change gear. Bed ways & surface of compound rest have been ultra-frequency heat treated & ground to provide a longer life. Dynamically balanced alloy spindle is adopted 3 points of bearing support. Length safety foot brake.
TECHNICAL SPECIFICATION
| Specifications | CA6261Ax2000 |
| Swing over Bed | 610 mm |
| Distance between Center | 2000 mm |
| Swing over Cross Slide | 380 mm |
| Bed Width | 400 mm |
| Width of Gap bed | 400 mm |
| Spindle Bore Diameter | 52 mm |
| Number of Spindle Speed | 24 steps |
| Range of Spindle Speeds | Range of Spindle Speeds: Min: Min:Maxm 80
rpm, Max:Minm 1400rpm |
| Spindle Nose | ISO (GB) C6 |
| Tail stock Travel of Barrel | 150 mm |
| Range of Metric Pitches | Range of Metric Pitches:Min: Maxm 0.2mm, Max:Minm 14mm; |
| Range of Diametrical Pitches | Range of Diametrical Pitches:Min: Maxm 8D.P, Max:Minm 44 D.P.; |
| Range of Longitudinal Feeds | Range of Longitudinal Feeds:Min:Maxm 0.04 mm /rev., Max:Minm 1 mm /rev., |
| Range of Cross Feeds | Range of Cross Feeds: Min:Maxm 0.05 mm /rev., Max:Minm 1.25 mm /rev.; |
| Main Spindle Motor | 7.5kw (10 HP) |
