Cutting capacity |
Height: 400 |
mm |
|
Width:700 |
mm |
Blade process Speed |
15-60 (frequency control) |
m/min |
Blade Size |
1.3*41*5650 |
mm |
Motor Output |
7.5 |
kw |
Hydraulic Pressure |
0.75 |
kw |
Coolant Pump |
0.09 |
kw |
Table height |
700 |
mm |
Machine weight |
2 |
ton |
Machine Size(L*W*H) |
2800x3100x1900 |
mm |
Vice clamping |
Hydraulic |
|
Hydraulic cooling way |
Wind cooling |
|
Feeding way |
Feeding hydraulic platform |
|
Feeding cut adjust way |
Dual hydraulic valve governor |
|
Voltage |
380V 50HZ 3Phase |
|
Chip conveyor way |
Hollow Screw style auto convey |
|
Blade tensioning form |
Manual |
