Equipment features：
1.The whole machine adopts a dust-proof and closed design, which is safe to operate.
2.It can be cut at a time to form a steel mesh with a maximum width of 6 meters.
It adopts hydraulic control mode, fast speed and high shear efficiency.
It is designed at an acute angle between the upper and lower scissors, and it is cut successively (reducing the working intensity of the whole machine) for easy maintenance and stable work.
3.It adopts a split cutter design, which does not require overall replacement, is convenient for maintenance and reduces costs; the cutter can be used on both sides to improve service life; and greatly reduces costs.
4.Through special heat treatment process control, the average wear is guaranteed to be about 1mm/30,000 times, which overcomes the shortcomings of conventional tool materials with high hardness and easy chipping, and the life span is increased by more than 3 times.
| Machine Model | MC6000Y | |||||
| Working width | 6.2m | |||||
| Working height | 950mm | |||||
| power | 11kw | |||||
| Cutting capacity | Diameter 6-Φ12mm single wire Mesh 50mm
(Steel bar strength HRB400Mpa) Max 60 lines |
|||||
| Hydraulic cylinder model | 125/110/100-279 | |||||
| Oil number | 46# | |||||
| cutting strength | 180KN | |||||
| Number of upper cutters | 12 | |||||
| Number of lower cutters | 12 | |||||
| Length of each cutter | 520mm | |||||
| Length, width and height | 6860*1800*1800mm | |||||
| Net weight | 4.2T | |||||
| Rebar diameter | 6 | 8 | 10 | 12 | ||
| Rebar grade | hardness | Tensile strength | Number of cut Rebar | |||
| Three grade | HRB400 | 360MPa | 120 | 100 | 60 | 40 |
