MODEL | GS 280 | ||
Maximum Cutting Capacity | round | Φ280mm | |
rectangular | 280mm( W) x 250mm( H) | ||
Bundle cutting capacity | Maximum | 240mm(W)x90mm(H) | |
Min | 160mm(W)x20mm(H) | ||
Drive Capacity | Main Motor | 2.2KW | |
Hydraulic Motor | 0.75KW | ||
Coolant Pump | 0.09KW | ||
Blade Speed | 40/60/80 by tower wheel | ||
Blade Size | 3850x27x0.9mm | ||
Work piece Clamping | Hydraulic Vise | ||
Blade Tension | Manual | ||
Main Drive | Worm wheel Drive | ||
feeding mode | Roller feeding | ||
Table Height | 650mm | ||
Machine Size (LxWxH) | 1750x2200x1500mm | ||
Weight (kg) | 1400 |
Main Feature :
1. It is suitable for large batch sawing of materials of the same size;
2. Automatic feeding, automatic cutting, and automatic cutting;
3. The man-machine interface replaces the traditional control panel and uses digital methods to set working parameters;
4. PLC programmable controller, easy to choose sawing method;
5. Positioning error ≤0.2mm;
6. The double-column hydraulic cylinder structure greatly prolongs the service life of the machine;
7. Hydraulic control cutting speed, stepless speed regulation;
8. Stable sawing and high precision;
9. Customizable: automatic collection device; a clamping device for cutting beam;
10. Scissor type, reverse rotation 45°.
