Reported by: ANTISHICNC Date: July 18, 2023
Name Specifications Unit Machine model EOE1530 Laser Source Raycus3000 W Water cooler Power 3 Kw Software Cypcut LS3000 Guide Taiwan Rack Taiwan Servo Motor Japanese Fuji 750W Reducer Japanese SHIMPO Minimum cutting width 0.08-0.1 mm Maximum cutting thickness 18Ca...... [Read More]
Reported by: ANTISHICNC Date:
Specifications CW61206*5000(20T) Capacity Max.swing over bed 2060mm Max swing over cross slid 1560mm Distance between centers 3m,4m,5m,6m,8m,10m,12m Width of bed 1180mm(Rectangular rail) Max.weigth of workpiece 20T Head Stock Spindle hole φ105mm Spindle taper φ140mm Tap...... [Read More]
Reported by: ANTISHICNC Date: June 27, 2023
Boring shaft Boring bar diameter mm 130 Spindle bearing inner diameter mm 140 Taper standard 7/24;BT50 Spindle speed range rpm 35-2500 Spindle drive system Z.F gearbox (cont./30min) spindle power Kw 22/26 The maximum output torque of the main shaft Nm 1460 Spindle maximum co...... [Read More]
Reported by: ANTISHICNC Date: June 10, 2023
Product Introduction: The XK/XH series CNC milling machine suitable for drilling , hole-expansion, reaming, bevel edge,and tapping, for surface milling, step plane ,slope ,and milling groove , for cutting and milling curve ,curve surface and cam. Have the function of step-less speed and autom...... [Read More]
Reported by: ANTISHICNC Date: June 6, 2023
Item Unit VTL3000ATC Max. swing diameter mm 3500 Table diameter mm 3000 Max. turning diameter mm 3400 Max.turning height mm 2000 Max.loading weight t 20 Maximum torque of worktable KN.m 100 Table speed range r/min 2～63 Vertical turret horizontal travel mm -50～1900 Verti...... [Read More]
Reported by: ANTISHICNC Date: May 24, 2023
Description YK8026 Parameter Unit Processing Capacity Coordinate Axis Number 6 Axis Gear Type Spur internal gear, cycloidal gear, helical internal gear Workpiece Max. Inner Dia. φ260 mm Max.workpiece thickness 150 mm Max. Hel...... [Read More]
Reported by: ANTISHICNC Date: May 17, 2023
Technical Specifications| Model BS-400 Cutting capacity(mm) 0° φ400mm □500x400mm 45° φ400mm □400x400mm Sawing angle 0˚~45˚ Sawing speed (m/min) 40/60/80m/min Band saw blade specification (mm) 4800×34×1.1mm Saw Band Tension manual Main motor power (kw) 3 Hydraulic moto...... [Read More]
Reported by: ANTISHICNC Date:
Technical Specifications BS–500G Capacity Circular @90° 350 mm Rectangular @90° 500×350 mm Circular @45° 330 mm Rectangular @45° 330×350 mm Blade size 4180x34x1.1 mm Motor 3kW,servo motor Packing size 223x222x170 cm N.W/G...... [Read More]
Reported by: ANTISHICNC Date: May 12, 2023
Specifications Unit TCK46A Maximum turning diameter on the bed mm Φ800 Maximum turning diameter over the slide mm 630 Maximum progress diameter Axis 630 / disc 800 Maximum turning length mm 1500 Spindle end type A2-11 Spindle through hole diameter mm Φ104 Bar di...... [Read More]
Reported by: ANTISHICNC Date: May 6, 2023
Item Specifications WXK630×2000 Unit Machine tool use Machining trapezoidal threads Machining workpiece gauge grid Workpiece length specifications 2000 mm Maximum milling length 1500 mm Machining workpiece diameter range 400-630 mm Screw rotation arbitrary ...... [Read More]
