ITM
|
Unit
|
VMC450
|
VMC550
|
VMC650
|
|
|
Travel |
X axis
|
MM
|
450
|
600
|
650
|
|
Y axis
|
MM
|
350
|
400
|
400
|
|
|
Z axis
|
MM
|
400
|
500
|
500
|
|
|
Spindle nose to table
|
MM
|
100-500
|
100-600
|
120-600
|
|
|
Spindle nose to column
|
MM
|
380
|
420
|
460
|
|
|
Feed
|
Max.x rapid feed
|
M/Min
|
12
|
15
|
20
|
|
Max.y rapid feed
|
M/Min
|
12
|
15
|
20
|
|
|
Max.z rapid feed
|
M/Min
|
10
|
12
|
18
|
|
|
Cutting feed
|
MM/Min
|
1-5000
|
1-5000
|
1-10000
|
|
|
Torque(x y z)
|
N.m
|
6/6/8
|
6/6/10
|
10/10/10
|
|
|
Table
|
Table size
|
MM
|
650*260
|
800*320
|
900*350
|
|
Max.load
|
KG
|
200
|
250
|
300
|
|
|
T slot
|
MM
|
3-14-80
|
3-14-100
|
3-14-90
|
|
|
Type
|
Belt (Taiwan)
|
||||
|
Speed
|
RPM
|
50-8000
|
50-8000
|
50-8000
|
|
|
Spindle bore
|
MM
|
120
|
120
|
120
|
|
|
Spindle taper
|
BT40
|
BT40
|
BT40
|
||
|
Pull stud
|
MAS403-BT-1
|
||||
|
Main motor
|
KW
|
2.2/3.7
|
3.7/5.5
|
5.5/7.5
|
|
|
Accuracy
|
Positioning Accuracy
|
MM
|
0.015/300
|
0.015/300
|
0.015/300
|
|
Repeatibility
|
MM
|
0.0075
|
0.0075
|
0.0075
|
|
|
Machine
|
Size( L W H)
|
MM
|
2000*1800*2240
|
2300*1800*2240
|
2200*1900*2400
|
|
Weight
|
KG
|
2300KG
|
1800KG
|
3200K
|
|
