Model: CA6266Cx1500
Brand: ANTISHICNC, Origin: China
| Main Features |
| 3–Axis position indicator |
| One-piece heavy-duty cast bed |
| Comprehensive metric, diametric, module, and Whitworth threading |
| Taper turning attachment for additional applications |
| Sturdy headstock design with large spindle bearings |
TECHNICAL SPECIFICATION
| Swing over Bed | 660mm |
| Distance between Center | 1500mm |
| Swing over Cross Slide | 400mm |
| Turning diameter wihout gap bridge | 890mm |
| Bed Width | 400mm |
| Width of Gap bed | 310mm |
| Spindle Bore Diameter | 105mm |
| Number of Spindle Speed | Forward Rotation: 24 Speeds;
Reverse Rotation: 12 Speeds |
| Range of Spindle Speeds | Forward Rotation: 10–1600 rpm
Reverse Rotation: 12.5–1600 rpm |
| Spindle Nose | ISO (GB) D8 |
| Tailstock Travel of Barrel | 230mm |
| Range of Metric Pitches | Mini: 0.25-Max:192mm |
| Range of Diametrical Pitches | Min: Maxm 0.88D.P, Max: Minm 160 D.P |
| Range of Longitudinal Feeds | Mini:0.028mm /rev
Max:1.59mm /rev. |
| Range of Cross Feeds | Mini:0.014mm /rev.
Max:0.86mm /rev. |
| Main Spindle Motor | 7.5kw |
Attachment/ Components
Follow rest
4-jaw faceplate chuck Ø 400 mm
Faceplate Ø 450 mm
3-axis position indicator
LED work light
Fixed splash guard (wall)
Quick tool changer head WC, quick change tool holder
Taper turning unit
Dead center and reducing sleeve (Tailstock is 5 MT)
Reduction sleeve MK 5/4
Rotating center point MK 4
