Heavy Duty Large CNC Vertical Machining Center for Moulds and Metal Parts

Machine Body Casting three linear guide ways high-strength body
Spindle original import Taiwan WLT / TD, 12000 rpm ,direct connection
System Original Japan imported control system the latest version Mitsubishi M80A
Spindle motor Imported Japan Mitsubishi servo motor 11KW
Three-axis motor Imported Japan Mitsubishi servo motor
Automatic lubrication system pressurized volumetric automatic oiler, automatic balance distribution of lubricants
(joint venture Baoteng brand oiler)
Head balance system The body comes with a counterweight balancing system
High pressure chip system high pressure motor, high pressure flushing (joint venture Sinaer brand water pump)
Screw original Taiwan imported Hiwin screw
Spindle cooling plus independent oil cooling system (joint venture Ruike brand oil cooler)
Tool Magazine Taiwan Sanjie arm type with 24 BT40 tools capacity
Controller standard Mitsubishi M80A color display
X, Y, Z bearings standard German FAG or Japan NSK
Triaxial roller screw standard Taiwan Taiwan Hiwin / PMI
Spindle Knife cylinder Standard Taiwan North Kui / Hao Cheng
Couplings Standard Germany BK3 SW*J
Wind system combined with solenoid valve (triple) standard joint venture Ogreut
The main electrical accessories standard Germany Schneider, Merlin Gerin
Other air pressure components standard joint venture Ogreut
Circuit breakers, relays standard Germany Schneider, Merlin Gerin
Electric box air fan standard joint venture FuRuize
Transformer standard joint venture AoHengda
Work LED lamp standard Taiwan Ou Si
Hand control electronic hand wheel standard Taiwan NEMICON
Three-axis telescopic shield standard joint venture Zhenfei
Full cover standard joint venture Jiancheng


X/Y/Z-Axis Travel 1200/700/600mm
Distance from Spindle Nose to Table 150-750mm
Distance from Spindle Center to Column Guide Rail 785mm
Working Table Size 1360*700mm
Table Max Load 1300kg
T Slot 5pcs,size:18T
Spindle Speed 12000rpm
Spindle Motor Power 11kw
X/Y/Z-Axis Motor Power 3.0/3.0/3.0kw
Rapid Traverse(X/Y/Z) 24000mm/24000mm/24000mm/min
Cutting Speed 0-10000mm/min
Spindle Taper Diameter BT40/150mm
Positioning Accuracy ±0.005mm/500mm
Repeat Positioning Accuracy ±0.003mm/500mm
Total Electricity Demand 25kw
Machine Size 4000mm*3000mm*2800mm
Machine Weight 10.5ton
  1. Tool box (1 set)
  2. Tool Holder(2 pcs)
  3. 6 inch vise (2 pcs)and Lock knife seat (1 set)
  4. Machine operating manual
  5. Operation and programming manual
  6. Servo Motor and Controller Manual
  7. High pressure spray gun(1 pcs)
