Application:
This machine can automatically process inner cylindrical surface, tapered surface, arc surface, end surface, etc. It can also process standard single thread and multiple threads such as metric system and inch system.
Feature:
1. High strength, widened frame, suitable for heavy duty cutting
2. Four-station power tool bar
3. Variable frequency stepless speed regulation
4. Standard configuration: manual chuck
5. Optional configuration: hydraulic chuck
Product main technical specifications:
Specifications | Units | CAK6150V |
Max.swing over bed | mm | 500 |
Max.swing over cross slide | mm | 280 |
Max.processing length | mm | 1000/1500 |
X/Z axis travel | mm | X:300 Z:1000/1600 |
Spindle nose | A2-8/11 | |
Spindle bore | mm | 82 |
Bar capacity | mm | 65 |
Max. spindle speed | rpm | 1800 |
Chuck size | mm | 250 |
Spindle motor | KW | 7.5 |
X/Z axis repeatability | mm | ±0.005 |
X/Z axis feed motor torque | N.m | 5/7.5(1 m) 7.5/10(1.5m) |
X/Z axis rapid traverse | m/min | 8/10 |
Tailstock sleeve dia. | mm | 75 |
Tailstock sleeve travel | mm | 200 |
Tailstock sleeve taper | # | MT5 |
Tool post type | 4 station electric tool post | |
Cutting tool shape size | mm | 25×25 |
Guide form | Flat bed | |
Total power capacity | KVA | 13 |
Machine dimension(LxWxH) | mm | 2950/3630x1520x1750 |
Net weight | kg | 2850 |
