The Feature of GZK4240
•Double column band saw, Mainly use to cut small material by groups, with high efficiency.
•Machine control by PLC.
•PLC setting cutting size and quantity, machine auto material feed and measure feeding length.
•PLC monitors machine work status
•Hydraulic clamp vice
•Material feed in by auto, feeding length measured by liner scale, feeding tolerance within 0.2mm.
•Can do OEM as customers requests.
|
SPECIFICATIONS of GZK4240
|
||
|
Max Cutting Capacity |
Round
|
400mm
|
|
Square
|
400mm
|
|
|
Saw blade |
Speed
|
22/40/60m/min
|
|
Size
|
1.3*41*5800mm
|
|
|
Tension
|
Manual
|
|
|
Cleaning
|
Wire brush and flood coolant
|
|
|
Motor Output |
main motor
|
4.0kw 380v 50hz (could customizes)
|
|
oil-pump motor
|
1.1kw
|
|
|
Material feeding
|
Auto feeding, 400mm/one time, multiple feed
|
|
|
Work Piece Clamp
|
Hydraulic
|
|
|
Color
|
Customized
|
|
|
Machine Weight
|
2400kgs
|
|
