What characteristics will affect the sawing performance of metal materials?

01. Strength and hardness of the material

The higher the hardness and strength of the workpiece material, the greater the cutting force, the greater the power consumed, and the higher the cutting temperature, which intensifies the wear of the tooth tip of the saw blade, and the worse the cutting performance. Especially for materials with high heat resistance of the workpiece material, the ratio of the hardness of the tooth tip material to the hardness of the workpiece material during high temperature cutting is reduced during high temperature cutting, the cutting performance becomes worse, and the tooth tip is more likely to wear. This is also the main reason for the poor machinability of certain heat-resistant steels and high-temperature alloy steels.

In addition, it is not that the lower the hardness of the material, the better the processing. Some metals such as low carbon, pure iron, and pure copper have low hardness, but have high plasticity and are not easy to process. Steels with moderate hardness are better processed, such as No. 45 steel. Although No. 10 steel is softer than No. 45 steel, the difficulty of sawing is greater than that of No. 45 steel. In order to obtain better processing surface quality, some users will appropriately increase the hardness of the material to facilitate processing.

In some materials, the material of the cut layer produces severe plastic deformation during the sawing process, which leads to hardening of the surface to be cut. After the material is work hardened, its hardness is much higher than the original hardness, causing wear of the tooth tip. Therefore, the more serious the work hardening phenomenon, the shorter the tool life, that is, the worse the workability of the material. Materials such as stainless steel and alloy materials have the characteristics of work hardening.

There are often a certain number of fine and hard inclusions in the metal structure, these inclusions have relatively high hardness), which causes severe abrasive wear on the tool, thereby reducing the machinability of the material.

02. Thermal conductivity of materials

The better the thermal conductivity of the workpiece material, the more heat is taken away by the chips and the workpiece is dissipated, which is more conducive to reducing the temperature of the cutting zone, reducing the wear of the tool, and improving the cutting processability. The thermal conductivity of example 45 steel is 50.2W/(m℃), while the thermal conductivity of austenitic stainless steel and superalloy is only 1/3-1/4 of that of 45 steel, which is lower than that of 45 steel. One of the main reasons. The thermal conductivity of copper, aluminum and their alloys is very large, 2-8 times that of 45 steel, which is one of the reasons for their good machinability.

03. Material toughness

Toughness is expressed by impact value. Materials with greater toughness absorb more work during cutting deformation, so the cutting force and cutting temperature are higher, and they are not easy to break chips, which affects the sawing workability. Some alloy structural steels are not only stronger than carbon structural steels, but also have higher impact values, so they are more difficult to process.

04. Plasticity of materials

The greater the plasticity of the material, the greater the plastic deformation during cutting, the higher the cutting temperature, and the tool is prone to bonding wear and diffusion wear. When cutting materials with high plasticity at low speeds, it is easy to produce chip edges, which affect the quality of surface processing, and materials with high plasticity are not easy to cut when cutting. However, when processing materials with too low plasticity, they become brittle materials, and the cutting force and cutting heat are concentrated near the cutting edge, aggravating the wear of the tool, and also affecting the machinability. For example, the hardness of 1Cr18NiTi stainless steel is similar to that of 45 steel, but its plasticity is very large, so its processing difficulty is much greater than that of 45 steel.

05. Material shape and specification

Due to the unique cutting method of band saw blades, the larger the material, the greater the cutting difficulty. A 100mm large P20 steel can be easily cut with any band saw blade on the market, but 800mm large P20 steel is not for ordinary saw blades. So friendly, because the cutting force must be transmitted to each tooth tip through a guide arm with a sawing span of at least 820mm, which places high requirements on the machining accuracy and back edge strength of the band saw blade. Therefore, many customers would rather choose high-end saw blades with high prices than try low-end saw blades with cheap prices.

The sawing performance of many stainless steel materials with thin-walled holes is also worse than that of conventional solids. The main reason is that the intermittent cutting brings greater impact force and more impact force to the tooth tip. At this time, the user needs to choose the tooth carefully. Shape and parameters.

06. Other properties of the material

Some other properties also have a certain influence on the machinability. For example, materials with a large linear expansion coefficient will expand and contract during processing, and the size of the workpiece will vary greatly, so it is not easy to control the accuracy. The material with low elastic modulus has a large elastic recovery during the forming process of the processed surface, and it is easy to cause strong friction with the flank surface. The chemical properties of certain materials also affect the machinability to a certain extent. For example, when cutting magnesium alloy, the powdery debris is easy to oxidize and combust. When cutting titanium alloys, oxygen and nitrogen are easily absorbed from the atmosphere at high temperatures to form hard and brittle compounds, which make the chips into short fragments. Cutting force and cutting heat are concentrated near the cutting edge, thereby accelerating the wear of the tooth tip.
