Recently, our company successfully exported 1 Set TG680 CNC Tool Grinding Machine and 1 Set X3 Grinding Wheel Machine to a company in Kazakhstan.
This client is a supplier of rotary die-cutting & converting tooling, specializes in manufacturing magnetic flexible dies, magnetic cylinders, precision rotary cutting/hot stamping/screen printing tooling and calibration equipment. They visited our factory last year, and they want a new machine to grind some tools which need to use on their generally production. They ever grind such tools by European machines. For now they want to purchase a new machine to grind their tools.
According to the drawing they sent to us, we recommend our TG680 CNC tool grinding machine to them, and before place the order, they sent some samples to us to have a test. They are satisfied with the test result and ordered on TG680 together with some auxiliary equipment, including X3 grinding wheel machine.
At present, this TG680 CNC tool grinding machine and the X3 grinding wheel machine is already on the way to our client and wait for to use it on his factory!
| Producer | Shanghai ANTS Machine Equipment Co.,LTD | Brand | ANTISHICNC | Origin country | Shanghai, China |
| Product Name | CNC Tool Grinding Machine and Grinding Wheel Machine | Model No. | TG680 & X3 | Export Country | Kazakhstan |
| Customer Introduction | This client need a CNC Tool Grinding machine to grind their tools. | ||||
| Equipment
Application |
TG680 is a high-precision CNC tool grinder designed for regrinding and manufacturing cutting tools. It supports processing drills, end mills, taps and mold cutters with multi-axis linkage for complex geometric edges. Equipped with high-speed spindle and precise positioning system, it ensures stable grinding accuracy. The intuitive control panel enables easy parameter setup. Widely used in mold, machinery and metalworking industries for mass or small-batch tool production and refurbishment. | ||||
 |
|||||
 |
|||||
 |
|||||
 |
|||||
 |
|||||
If you want to order the same product, please open the link below!
six-axis-five-linkage-cnc-tool-grinder-tg680
x3-series-large-size-grinding-wheel-dresser
Packing size information:
| DESCRIPTION&SPECIFICATION | PACKAGES | N.W(KGS) | G.W(KGS) | Packing Size(mm) | Volume(CBM) |
| TG680 CNC TOOL GRINDING MACHINE | 1 | 3654 | 4079 | 2280*2200*2500 | 12.54 |
| ACCESSORIES | 1 | 730 | 762 | 1780*1160*1600 | 3.3 |
| 1 | 140 | 164 | 1000*770*1270 | 0.97 | |
| 1 | 130 | 152 | 940*740*1350 | 0.93 | |
| 1 | 70 | 103 | 980*760*880 | 0.65 | |
| X3 STANDARD GRINDING WHEEL DRESSER | 1 | 1010 | 1300 | 1450*1350*2100 | 4.11 |
| Total | 6 | 5734 | 6560 | 22.5 | |
