3 Axis Surface Grinder Surface Grinding Machine Manufacturer
| Parameters |
Unit |
KGS1224AH |
|
| Working Surface of Table |
mm |
300×600 (12″×24″) |
|
| Max.Table Travel |
mm |
660 |
|
| Max.Cross Travel |
mm |
340 |
|
| Distance Between Table Surface and Spindle Center |
mm |
520 |
|
| Max.Table Load |
kgs |
420 |
|
| T-Solt (Number×Width) |
mm |
1×14 |
|
| Table Speed |
m/min |
5-25 |
|
| Cross feed Handwheel |
1gard |
mm |
|
|
1 rev |
5 |
||
| Automatic Cross feed of Saddle |
mm |
0.5-12 |
|
| Power Cross Feed |
50HZ |
mm/min |
790 |
|
60HZ |
950 |
||
| Grinding Wheel Dimensions |
mm |
355×40×127 |
|
| Spindle Speed |
50HZ |
rpm |
1450 |
|
60HZ |
1740 |
||
| Vertical Handwheel |
1gard |
mm |
0.001 |
|
1 rev |
0.5 |
||
| Automatic Down Feed Rate |
mm |
0.005—0.025 |
|
| Power Head Increment |
mm/min |
230 |
|
| Spindle Motor |
kw |
4 |
|
| Vertical Motor |
w |
90 |
|
| Hydraulic Motor |
kw |
1.5 |
|
| Dust Collection Motor |
w |
550 |
|
| Coolant Motor |
w |
90 |
|
| Crossfeed Motor |
w |
90 |
|
