Technical parameter:
| Techncial parameters | Unit | H3 APC | H4 APC | H5 APC | H6 APC |
| Wortable size | mm | 300×300 | 400×400 | 500×500 | 630×630 |
| Worktable number | – | 2 | 2 | 2 | 2 |
| Worktable indexing | ° | 0.001° | 0.001° | 0.001° | 0.001° |
| Worktable loading capacity | kg | 250kgx2 | 1000kgx2 | 600kgx2 | 1000×2 |
| T slot of worktable (No.-sizexdistance) | – | 24-M12(80×80) | 5-14×80 | 5-14×100 | 24-M16 (125×125) |
| X axis travel | mm | 460 | 600 | 900 | 1050 |
| Y axis travel | mm | 350 | 600 | 800 | 900 |
| Z axis travel | mm | 350 | 600 | 800 | 1050 |
| Distance from spindle center to worktable | mm | 60-410 | 0-600 | 0-800 | 0-900 |
| Distance from spindle nose to
wortable center |
mm | 100-450 | 150-750 | 125-925 | 160-1210 |
| Spindle taper (Style/diameter) | – | BT40-Φ120 | BT40-Φ120 | BT50-Φ190 | BT50-Φ190 |
| Max. spindle speed | rpm | 10000 | 10000 | 6000 | 6000 |
| ATC style/station | – | Disc/24pcs | Disc/24pcs | Disc/24pcs | Disc/24pcs |
| Max. tool diameter | mm | 300 | 300 | 350 | 350 |
| Max. tool length | mm | Φ80 | Φ80 | Φ127 | Φ127 |
| Max. tool weight | kg | 7 | 7 | 15 | 15 |
| X/Y/Z Rapid moving speed | m/min | X:36 Y:36 Z:36 | X:36 Y:36 Z:36 | X:36 Y:36 Z:36 | X:32 Y:36 Z:36 |
| X/Y/Z Rail style | – | Linear | Linear | Linear | Linear |
| Main motor | kw | 5-7.5 | 15-18.5 | 15 | 15-18.5 |
| X/Y/Z Feeding motor | NM | X:12 Y:12 Z:12 | X:22 Y:22 Z:22 | X:26 Y:26 Z:26 | X:30 Y:30 Z:30 |
| Net weight (appox.) | kg | 6300 | 15000 | 10000 | 15000 |
| Overall dimension (LxWxH) | mm | 2220x3000x2400 | 2620x4000x2600 | 3530x4600x2800 | 3800x6200x3200 |
Main configuration & accessories:
1. Resin sand casting;
2. X, Y, Z rails adopts imported linear guideway;
3. X, Y, Z rails adopt stainless steel telescopic cover;
4. Standard with belt driven spindle, H3APC/H4APC is direct driven spindle;
5. Taiwan production pneumatic cylinder;
6. Taiwan ATC,disc type and chain type are available as option;
7. Imported bearings for leadsrews;
8. Import coupling;
9. Headstock balancing system have nitrogen balance system or hydraulic balance system as option;
10. Exchangeable NC rotary worktable (B axis);
11. Work lamp;
12. Pilot lamp;
13. USB and Internet interface;
14. Manual pulse generator (MPG);
15. Centralized automatic lubrication system.
16. Cooling system.
17. Heat exchanger for electrical cabinet ;
18. Leveling blocks & bolts;
19. Toolbox and tools;
20. CNC controller: KND,GSK, HNC (China); SIEMENS, FANUC, MITSUBISHI, FAGOR, etc.
Optional configuration & accessories:
1. ZF or BF reducer;
2. Circular Coolant Nozzle;
3. Coolant through spindle (CTS);
4. Spindle oil cooler;
5. Air conditioner (A/C) for electrical cabinet;
6. Auto. Tool length measurement system;
7. Auto. Workpiece measurement systems;
8. Chain type chip conveyor;
