| Features and Construction: |
| Table can swiveled to each 45° right and left |
| Vertical spindle rotation will be driven through the horizontal spindle. |
| Support bracket will be suitable for heavy duty machining. |
| There must be option to transmit power from table lead screw to Universal dividing head through change gear. |
| Capable to cut/ mill spur and helical gear. |
TECHNICAL SPECIFICATION
| Table: | |
| Working surface of table Worktable size(L×W)： | 1325x360mm |
| X- axis travel | 750 mm |
| Y-axis travel | 320 mm (Without DRO) |
| Z-axis travel | 450mm |
| Range of longitudinal feed speed | Range of longitudinal feed speed: Min: Maxm 20 mm/min, Max: Minm 500 mm/min ( 6 steps) |
| Range of longitudinal rapid speed | 800mm /min |
| Table swivel (R & L) | +/- 45° |
| Maximum load bearing of worktable | 350kg |
| Horizontal Main Spindle: | |
| Range of spindle speeds | Range of spindle speeds: Min: Max m 60, Max: Minm 1800 rpm (Min 6-steps) (12 Steps) |
| Taper of spindle bore | Taper of spindle bore: 7:24, ISO50 |
| Spindle center to table | 450mm |
| Spindle center to over arm bottom | 200 mm |
| Motor: | |
| Horizontal milling (vertical milling head) | Motor power (Universal milling head) : 5.5(HP) 4(V) |
| Table longitudinal feed | 2 HP |
| Coolant pump | 1/8 HP |
