Features:
The saw frame can be rotated 0-45 degrees to realize the angle sawing of materials.
PLC, set the cutting process.
Grating positioning feed length, single precision feed is controlled within 0.2mm.
The processing size can be set to 5 groups.
Each set of feeding length can be set to 50000mm.
The number of processing elements in each group is 1-999.
At the same time, loosen the jaws to make the jaws easy to wear.
With cut-off protection function, the machine can automatically stop when sawing a piece or a tape to protect the machine and the workpiece.
It can be disassembled and clamped on the hydraulic pressure, so that root and multi-layer parts can be sawed at the same time.
| MODEL | GWZ4235 | GWZ4250 |
| Cutting Capacity(mm) | 0° Circular 350 Rectangular 350*350 45° Circular 350 Rectangular 350*350 |
0° Circular 500 Rectangular 650*500 45° Circular 500 Rectangular500*500 |
| Blade Speed(m/min) | 30/46/58/83 | 21/42/68 |
| Blade Specifications(mm) | 1.1*34*4115 | 1.3*41*5300 |
| Main Motor power(kw) | 4 | 4 |
| Hydraulic Motor power(kw) | 0.75 | 1.5 |
| Machine Size(mm) | 2100*2000*1350 | 2650*2000*1800 |
| Work piece | Hydraulic | Hydraulic |
