TURRET MILLING MACHINE FEATURES:
Feature of X6323
Double 55° swallowtail guide way is adoped on both Y, Z-axis, so it is easy to adjust and repair.
Adopted strengthen rib on both ides of the column that makes the machine rigidly and beautiful.
Feature of X6325:
Rectangular guide way on Y-axis and Z-axis is feature a good rigidety
The guide way on saddle is lined with TF wearable material
The worktable surface and 3 axis guide way are hardened and precision ground.
Feature of X6325D:
Rectangular guide way is adopted both on Y and Z axis.
The guide way on saddle is lined with TF wearable material. Which makes the machine stably
and rigidly, also makes it beautiful and easy to operate.
5HP milling head motor and quill diameter is 100MM.
Feature of X6333
Double 55° swallowtail guide way is adoped on both Y, Z-axis, so it is easy to adjust and repair.
Adopted strengthen rib on both ides of the column that makes the machine rigidly and beautiful.
Feature of X6330A
Double 55° swallowtail guide way is adoped on both Y, Z-axis, so it is easy to adjust and repair.
Adopted strengthen rib on both ides of the column that makes the machine rigidly and beautiful.
| MODEL | X6323A | X6325 | X6325D | X6333 | X6330A | |
| Table size | 230*1067 230*1246 |
254*1270 254*1370 |
254*1270 254*1370 |
330*1370 330*1500 |
305*1370 305*1500 |
|
| Long travel(mm) | 650 840 | 850 950 | 850 950 | 840 1000 | 870 1000 | |
| Cross travel(mm) | 305 | 420 | 420 | 368 | 380 | |
| Vertical travel(mm) | 350 | 420 | 420 | 450 | 430 | |
| T-slot No.and size(mm) | 3×16 | |||||
| Ram travel(mm) | 315 | 470 | 470 | 500 | 500 | |
| Distance from spindle nose to table surface(mm) |
0-350 | 0-405 | 0-405 | 0-450 | 0-350 | |
| Spindle hole taper | Standard:R8 | standard:ISO40 | ||||
| Spindle travel(mm) | 127 | |||||
| Spindle speed(r.p.m) | standard: shift grade 16, 50HZ 65-4500,60HZ80-5440 | |||||
| optional:variable:60-4200 | ||||||
| Auto.quill feed | Three steps:0.04/0.08/0.15mm/revolution | |||||
| Spindle motor | 2.25kw/3hp | 2.25kw/3hp | 3.75kw/5hp | 3.75kw/5hp | 3.75kw/5hp | |
| Head swivel | 90° | |||||
| Head tilting | 45° | Fix | ||||
| Dimension of package | 1400 x1476x2030 |
1516 x1550x2080 |
1516 x1550x2080 |
1800 x2016x2180 |
1566 x1650x2080 |
|
| G.W/set | 1100 | 1550 | 1590 | 2300 | 1750 | |
