Metal Cutting Band Saw Machine for Stainless Steel or Various Metal

high capacity band control by two speed motor.

· Vertical rotation on bolt with adjustable tapered bearings without backlash.

· Band stretching is obtained by electro-mechanical blade tensioner with micro switch.

· Hydraulic clamping vise.

· Swivel on both sides.

· Electric coolant system.

· Display control panel.

SPECIFICATIONS:
· Motor: 3 HP, 220V/440V, 3 Phase, prewired 220V.

· Gear drive.

· Capacity round 90°: 13″.

· Capacity rectangular 90°: 18″ x 10″.

· Capacity round 60°: 8″.

· Capacity rectangular 60 °: 8″ x 10″

· Capacity round±45°: 12″.

· Capacity rectangular 45°: 12″ x 10″

· Blade speed: 153-1/2 FPM,307-1/4 FPM.

· Blade size: 156″ x 1″ x 0.035″

· Packing size: 91″ x 42″ x 64″.

· Net weight and shipping weight: 1716 LBS, 1826 LBS

Model
BS-712N
Capacity for circular at 90°
178mm (7″)
Capacity for circular at 45°
127mm (5″)
Capacity for rectangular at 90°
178*305mm (7″*12″)
Capacity for rectangular at 45°
120*125mm (4.75″*4.88″)
Blade speed for 60Hz
27,41,59,78MPM
Blade speed for 50Hz
22,34,49,64MPM
Blade size
20*0.9*2362mm
Motor power
750W 1HP (3PH),1.1KW 1.5HP (1PH)
Driver
V-belt
Packing size
125*45*115cm
N.W
145KG
G.W
178KG
