Worktable size
|
mm
|
305*635
|
|
|
Magnetic chuck size
|
mm
|
300*600
|
|
|
Max. distance from spindle center to table
|
mm
|
580
|
|
|
Table cross travel
|
mm
|
340
|
|
|
Table logitudinal travel
|
mm
|
765
|
|
|
Max. loading capacity (include chuck)
|
kg
|
270
|
|
|
Speed of worktable longitudinal move
|
m/min
|
5-25
|
|
|
Worktable cross movement
|
Intermittent feed rate
|
mm/t
|
0.1-8
|
|
Rapid feed
|
m/min
|
990
|
|
|
Feed of handwheel
|
mm/div
|
0.02
|
|
|
wheelhead vertical movement
|
Auto down feed rate
|
mm/t
|
0.005-0.05 (only model AHD)
|
|
Rapid down speed
|
m/min
|
AHR: 650 / AHD: 480
|
|
|
Feed of handwheel
|
mm/div
|
0.005
|
|
|
Spindle rotating speed
|
r/min
|
1450 (50HZ) / 1750 (60HZ)
|
|
|
Grind wheel size
|
mm
|
350*40*127
|
|
|
Spindle motor power
|
kw
|
4
|
|
|
Floor space (LxWxH)
|
mm
|
2900*2200*1900
|
|
|
Gross weight
|
kg
|
2800
|
|
|
Package size (LxWxH)
|
mm
|
2350*2220*2210
|
|
